Skip to content Russ moves from theory into practical testing on the Tangerine Tiger platform, using a 5 W diode head to see what a small blue diode laser can actually do. The session starts to connect timing, motion and burn quality with the physics discussed earlier.
Previous: Session 03 | Series Menu | Next: Session 05
What You’ll Learn
- How a 5 W diode behaves in practical engraving tests.
- Why timing, motion and exposure influence the mark.
- How early test results can challenge assumptions about low-power diode heads.
A 5 W Diode in the Real World
The first practical results are better than Russ expected. By controlling the mechanics and working conditions carefully, he begins separating genuine beam behaviour from limitations imposed by a typical hobby machine.
Timing, Pixels and Motion
The session also introduces pixel placement, scanning and timing issues that later become important in image engraving.
Why This Session Matters
This is where the series begins turning theory into measurable workshop evidence.
This page is a concise overview of the original video rather than a full transcript.
