Skip to content Russ develops the previous session into a fuller model of diode cutting. He examines intensity, focus and the evolving carbonised zone to explain why the kerf can stay relatively straight even though a simple ray diagram would suggest a much more tapered result.
Previous: Session 27 | Series Menu | Next: Session 29
What You’ll Learn
- How intensity and exposure combine to drive the cut.
- Why the active cutting zone is not simply the geometric outline of the beam.
- Why starting focus and later depth adjustment have different effects.
The Material Selects the Useful Part of the Beam
Only the region above the damage threshold contributes strongly to cutting. As the process develops, the highly absorbing carbonised zone concentrates the interaction and can produce a much narrower effective cutting region than the full optical beam.
Focus Is an Intensity Problem
Russ distinguishes a useful intensity focus from a simple geometric focus. Moving too far from the highest-intensity zone reduces cutting ability, even if a visible spot is still present.
Why This Session Matters
This is one of the key synthesis sessions in the series, bringing optics, material response and practical cutting together.
This page is a concise overview of the original video rather than a full transcript.
